3003 Aluminum Strip

Properties Strength Packaging and Delivery

3003 aluminum strip is a type of aluminum alloy that is primarily composed of aluminum with manganese as the main alloying element. It belongs to the 3000 series of aluminum alloys, which are known for their good corrosion resistance, moderate strength, and excellent workability.

Besides of aluminum 3003 strip, we also can supply 3003 aluminum sheet, 3003 aluminum plate, 3003 aluminum coil and 3003 aluminium circle.

Specification of 3003 Aluminum Strip:

Products	3003 aluminium strip
Alloy temper	F,O,H12,H14,H16,H18,H19,H22,H24,H26,H28
Available dimension	Thickness: 0.5-6.0 mm; Width: 100-1000 mm; Length: strip, Can be cut to customized sizes.
Standards	ASTM-B209,EN573-1,GB/T3880.1-2006
Application	Industry, decoration, building, packing, pressing, etc.
MOQ	300 kgs/size
Lead time	7-25 days
Payment terms	TT, L/C

3003 Aluminum Strip Chemical Composition

Element	Value
Al	98.6-99.7
Mn	1.0-1.5
Fe	0.7-1.2
Cu	0.05(max)
Sn	0.05(max)
Zr	0.05(max)
Si	0.6(max)
Cr	0.1(max)
V	0.05(max)

3003 Aluminum Strip Mechanical Properties

Tensile Strength (σ): 130 MPa (approx.)

Yield Strength (σ0.2): 125 MPa (approx.)

Elongation (A50): 15% (approx.)

3003 Aluminum Strip Physical Properties

Density: 2.73 g/cm³

Melting Point: 655°C

Thermal Conductivity: 190 W/(m·K)

Electrical Conductivity: 30% IACS

Features of 3003 Aluminum Strip:

1. Corrosion Resistance

3003 aluminum strip has excellent corrosion resistance, making it suitable for applications where exposure to moisture or corrosive environments is a concern.

2. Formability and Processability

This alloy exhibits good formability and is easily processed through methods such as bending, deep drawing, and roll forming, making it adaptable to various manufacturing techniques.

3. Weldability

3003 aluminum strip is highly weldable, allowing for efficient joining processes. It can be welded using various methods, including arc welding and resistance welding.

4. Moderate Strength

While not as strong as some other alloys, 3003 aluminum offers moderate strength, sufficient for many applications where high strength is not the primary requirement.

5. Ease of Machining

The alloy's composition contributes to its machinability, allowing for ease of machining and fabrication.

Applications of Aluminium 3003 Strip:

3003 aluminium is widely applied in various fields, including cookware, containers for food and chemical product processing and storage, tanks and vats for transporting liquid products, heat sinks, cosmetic panels, photocopier drums, shipbuilding materials, base materials for color-coated aluminum, base materials for roofing sheets, curtain wall aluminum panels, pipe insulation, electronic stamping components, storage bins, satellite dish materials, battery shell materials, battery cover plates, and water-cooled plates for new energy vehicles.

3003 Aluminum Strip for Electrical Industry

Width: 20-100mm

Temper: O (Annealed)

Specifications: ASTM B209, EN 485

Example: Electrical connectors, small components in electronic devices.

3003 Aluminum Strip for Automotive Trim

Width: 100-300mm

Temper: H14, H16

Specifications: AMS 4008, ASTM B209

Example: Trim strips, decorative elements in automotive interiors.

3003 Aluminum Strip for Roofing and Cladding

Width: 300-600mm

Temper: H24

Specifications: ASTM B209, EN 573

Example: Roofing panels, architectural components.

3003 Aluminum Strip for Heat Exchanger Fins

Width: 600-1200mm

Temper: H16, H18

Specifications: AMS 4008, ASTM B209

Example: Fins for heat exchangers, evaporator coils.

3003 Aluminum Strip for Building Facades

Width: 1200+mm

Temper: H18

Specifications: AMS 4008, ASTM B209

Example: Large structural components, building facades.

Strength of Haomei Al.

Technologies:Top polishing technology guarantees good luster and smooth surface.
Markets:Obtain market sharing all over the world.
Equipment:Advanced cutting line to provide a wide range of specifications.
Production capacity:200, 000 tons annually in total.
Employees:Over 25 sale persons to provide good service for customers.
Responsibility: Engaged in charity donation and provide eco-friendly products.

Packaging and Delivery of Haomei Al.

Aluminum products of Haomei Al. meet the export standard. Plastic film and brown paper can be covered at customers’ need. What’s more, wooden case or wooden pallet is adopted to protect products from damage during the delivery. There are two kinds of packaging, which is eye to wall or eye to sky. Customers can choose either of them for their convenience. Generally speaking, there are 2 tons in one package, and loading 18-22 tons in 1×20′ container, and 20-24 tons in 1×40′ container.
