3104 Aluminum Strip

Properties Strength Packaging and Delivery

3104 aluminum strip(AL-Mn) belongs to modification aluminum alloy strip, the temper including H111 / 0 / H14 / H16 / H18 / H34, etc. The maximum tensile strength can be controlled equal or at greater than 275MPA, elongation up to 20%. 3104 aluminum strip has good deep-drawing property, which is suitable for thinning the tensile lightweight materials to reduce the quantity of material. The procedure of tank process has strict requirements. In order to obtain high-quality billets, From the beginning of hot-rolled, cold-rolled to finishing workshop, each process is strictly controlled by our company and more attention is paid to control the thickness of the plate, the surface, mechanical properties and anisotropy, so as to make products obtain appropriate strength and formability.

Specification of 3104 Aluminum Strip:

Products	3104 aluminium strip
Alloy temper	F,O,H12,H14,H16,H18,H19,H22,H24,H26,H28,H111,H112,H114
Available dimension	Thickness: 0.5-6.0 mm; Width: 100-1000 mm; Length: strip Can be cut to customized sizes.
MOQ	300 kgs/size
Lead time	7-25 days
Tolerances	As customer’s requirement
Loading Port	Qingdao Port,Tianjin Port,Shanghai port.
Price terms	FOB, CIF, CFR, CNF, etc.
Payment terms	TT, L/C,D/A,D/P,T/T , West Union, Money Gram, Etc.

Chemical Composition of 3104 Aluminium Strip

Elements	Si	Fe	Cu	Mn	Mg	Cr	Others	Al
Content	≤0.50	≤0.70	≤0.10	0.9~1.5	≤0.30	≤0.10	0.05	Remain

Mechanical properties of aluminum Strip 3104:

Aluminium 3104 is a commonly used Al-Mn (aluminum-manganese) alloy, known for its excellent formability and is classified as a wrought aluminum alloy. It features a tensile strength of at least 275 MPa and an elongation rate of up to 20%. These properties make it highly suitable for deep drawing processes, allowing for material thinning and lightweighting while maintaining structural integrity.

The production of aluminum 3104 requires strict control over each manufacturing process, especially when used for can body materials. Our company adheres to stringent quality standards, ensuring that each process is meticulously managed to achieve the optimal balance of strength and formability in the final product.

Applications of 3104 Aluminum Strip:

Aluminium 3104 is widely used in various applications, including aluminum louvers, lamp holder materials, can stock for beverage cans, anodized materials, mobile phone battery casings, automotive fuel tanks, aluminum substrates for color coating, and beverage cups such as those for soft drinks and beer.

Strength of Haomei Al.

Technologies:Top polishing technology guarantees good luster and smooth surface.
Markets:Obtain market sharing all over the world.
Equipment:Advanced cutting line to provide a wide range of specifications.
Production capacity:200, 000 tons annually in total.
Employees:Over 25 sale persons to provide good service for customers.
Responsibility: Engaged in charity donation and provide eco-friendly products.

Packaging and Delivery of Haomei Al.

Aluminum products of Haomei Al. meet the export standard. Plastic film and brown paper can be covered at customers’ need. What’s more, wooden case or wooden pallet is adopted to protect products from damage during the delivery. There are two kinds of packaging, which is eye to wall or eye to sky. Customers can choose either of them for their convenience. Generally speaking, there are 2 tons in one package, and loading 18-22 tons in 1×20′ container, and 20-24 tons in 1×40′ container.
