3105 Aluminum Strip

Properties Strength Packaging and Delivery

3105 aluminum strip is a non-heat-treatable alloy with excellent corrosion resistance, good formability, and high weldability. It belongs to the 3000 series of aluminum alloys, which are primarily composed of manganese as the major alloying element.

3105 aluminium strip is a versatile Al-Mn (aluminum-manganese) alloy known for its excellent corrosion resistance, good electrical conductivity, and formability. In the annealed state, it exhibits high ductility, making it suitable for deep drawing and forming processes. While its ductility decreases during partial cold working, it remains manageable, but it becomes significantly lower when fully cold-worked. The alloy also offers excellent corrosion resistance and weldability, though its machinability is relatively poor.

Temper H14: Strips are partially annealed, making them suitable for forming.

Temper H16: Strips are substantially annealed, providing increased hardness.

Specification of 3104 Aluminum Strip:

Products	3105 aluminium strip
Alloy temper	F,O,H12,H14,H16,H18,H19,H22,H24,H26,H28,H111,H112,H114
Available dimension	Thickness: 0.5-6.0 mm; Width: 100-1000 mm; Length: strip Can be cut to customized sizes.
MOQ	300 kgs/size
Lead time	7-25 days
Tolerances	As customer’s requirement
Loading Port	Qingdao Port,Tianjin Port,Shanghai port.
Price terms	FOB, CIF, CFR, CNF, etc.
Payment terms	TT, L/C,D/A,D/P,T/T , West Union, Money Gram, Etc.

Chemical Composition of 3104 Aluminium Strip

Grade	Si	Fe	Cu	Mn	Mg	Cr	Ni	Zn	Al
3105	0.6	0.7	0.3	0.30-0.8	0.20-0.8	0.2	-	0.4	remains

3105 Aluminum Strip Mechanical Properties

Tensile Strength: 160 MPa (23, 000 psi)

Yield Strength: 125 MPa (18, 000 psi)

Elongation: 20%

3105 Aluminum Strip Physical Properties

Density: 2.73 g/cm³

Melting Point: 643°C (1, 189°F)

Advantages of 3105 Aluminum Strip:

1. Excellent Corrosion Resistance

2. Good Formability

3. High Weldability

Applications of Aluminum Strip 3105:

Aluminium 3105 is widely used in various applications, including room partitions, barriers, mobile home panels, gutters and downspouts, thin sheet metal components, bottle caps for alcoholic beverages and soft drinks, cosmetic container lids, coated rolls, and more.

Strength of Haomei Al.

Technologies:Top polishing technology guarantees good luster and smooth surface.
Markets:Obtain market sharing all over the world.
Equipment:Advanced cutting line to provide a wide range of specifications.
Production capacity:200, 000 tons annually in total.
Employees:Over 25 sale persons to provide good service for customers.
Responsibility: Engaged in charity donation and provide eco-friendly products.

Packaging and Delivery of Haomei Al.

Aluminum products of Haomei Al. meet the export standard. Plastic film and brown paper can be covered at customers’ need. What’s more, wooden case or wooden pallet is adopted to protect products from damage during the delivery. There are two kinds of packaging, which is eye to wall or eye to sky. Customers can choose either of them for their convenience. Generally speaking, there are 2 tons in one package, and loading 18-22 tons in 1×20′ container, and 20-24 tons in 1×40′ container.
