Color Coated Aluminum Coil

sales@aluminumhm.com Get samples and prices !

Cut to size at customers' need !

Add to Product Favorites
Share

Introduction of Color Coated Aluminum Coil/Sheet

HAOMEI----specializes in producing color coated aluminum coil for Exterior and Interior applications. Color coated aluminum coil are widely used in ACP,curtain panel,honey comb panel,shutter,roofing and most of the decoration areas. About the color coated aluminum coil, we have introduced in most advanced computerized metal processing equipment ,Pre-treatment by the German pharmaceutical Henkel and Kenema Mittel. PPG paint coatings using the United States, Sweden BECKER paint, the United States Lili valspar paint. PVDF, perfluorocarbons can be divided into surface coatings, self-cleaning nano-Kang Wu fluorocarbon coating, coated polyester, acrylic coating.With the superior quality and advanced management,our products color coated aluminum coil had been export to Euro, Middle East, North America ,East Asia and many other areas and countriers.

Applications of Color Coated Aluminum Coil Sheet

For its lightweight, beautiful appearance, as well as good anti-correction, color coated aluminum Sheet and Coil are vastly used in construction for decoration, trasportation, household appliance, elastic cap stock, etc.

Specification of color coated aluminum sheet coil

Specification of Color Coated Aluminum Coil
Substrates: Aluminium (AA1100, 3003, 3004, 3105, 5006, 5052, 8011, etc), etc.
Thickness: 0.08-4.0mm
Width: <1800mm
Coils core diameter: 150mm ,405mm, 505mm, 508mm, 510mm
Coating thickness: PVDF >=25micron POLYESTER>=18micron
Color standard: E < 2 or it is not obvious by eyeballing
Pencil hardness: > 2HB
Coating adhesive: not lower than first grade Impact: no any crack (50kg/cm, ASTMD-2794:1993)
Bend stength: >100 times
Boiling point: no any distortion and color change (in the 99 more or less 1 degree water, then cooling 2 hours)
Corrosive: surface deep in the 5% muriatic acid and 5% NaCL, interior deep in the 2% muriatic acid and 2% NaCL, after 48 hours, no change

Parameters of PVDF Coating
Item Result Test standard
Coating thicknesss ≥ 25 μm ISO 2360 ( CNS 8406 )
Pencil Hardness ≥ 1H ASTM D3363
Color Retention Aging resistance test 4000 hours, maximum 5 units ASTM D2244
Glossr Retention Aging resistance test 4000 hours, 90% ASTM D2244
Chalk resistanc Aging resistance test 4000 hours, maximum 8 units ASTM D659
Flexibility( T shape bending ) IT, no crack ASTM D4145
Adhesiv 1mm×1mm,No peeled off ASTM D3359
Impact resistance No crack, no dropout ASTM D2794
Friction resistance 64.6 L/mil ASTM D968
Salt spray resistance 3000 hours no change( 5%NaCL,35℃) ASTM D117
Humidity resistance 3000 hours no change( 100RH35℃) ASTM D714
Mortar Resistance No change ASTM D605
Acid-resistance and alkali-resistance No change ASTM D1308
Solvent resistanc No change MEK 100times ASTM D2248

Strength of Haomei Al.
  • Technologies:Top polishing technology guarantees good luster and smooth surface.
  • Markets:Obtain market sharing all over the world.
  • Equipment:Advanced cutting line to provide a wide range of specifications.
  • Production capacity:200, 000 tons annually in total.
  • Employees:Over 25 sale persons to provide good service for customers.
  • Responsibility: Engaged in charity donation and provide eco-friendly products.
Packaging and Delivery of Haomei Al.

Aluminum products of Haomei Al. meet the export standard. Plastic film and brown paper can be covered at customers’ need. What’s more, wooden case or wooden pallet is adopted to protect products from damage during the delivery. There are two kinds of packaging, which is eye to wall or eye to sky. Customers can choose either of them for their convenience. Generally speaking, there are 2 tons in one package, and loading 18-22 tons in 1×20′ container, and 20-24 tons in 1×40′ container.
