3003 Aluminum Coil

sales@aluminumhm.com Get samples and prices !

Cut to size at customers' need !

Add to Product Favorites
Share

Properties of 3003 Aluminum Coil

3003 aluminum alloy is an aluminium-manganese alloy which approximately 20% stronger than alloy 1100. This alloy is readily formed by either conventional cold working or hot working. Haomei offers 3003 aluminum coil, sheet, plate and tread plate covered by the ISO standard 6361 and the ASTM standards B209, B210, B211, B221, B483, B491, and B547. The 3003-H14 is a softer, more formable aluminum sheet and 3003 tread plate offers increased rigidity in the material as well as hiding fingerprints and dents. Commonly used tempers include H14, H16 and H18 while others are also available by customers’ demands.

Alloy No.

Si

Fe

Cu

Mn

Mg

Cr

Zn

Ti

Others

Al

3003

0.6

0.7

0.05-0.20

1.0-1.5

0

0

0.10

0

0.20

REMAIN

3003 Aluminum Alloy Products

Products

Type

Temper

Thickness(mm)

Width(mm)

Length(mm)

3003 Aluminum Sheet

Painted,

Bare, Mill Finish

Tread plate

O

H14

H16

H18

0.2-4.5

100-2600

500-16000

3003 Aluminum Coil

0.02-0.055

100-1600

Coil

3003 Tread Plate

0.8-7.0

100-2600

500-16000













Features and Applications of 3003 Aluminum Coil

AL 3003 is an alloy with very good corrosion resistance and moderate strength. Excellent weldability, formability, with good machinability makes 3003 Aluminum coil, sheet and tread plate is popular and economical choice in Appliance Components. Alloy 3003 can be cold worked to produce tempers with a higher strength but a lower ductility while not heat-treated or used in casting. It is commonly rolled and extruded as aluminum sheet and foils which in different applications such as truck and trailer roofing, cooking utensils, pressure vessels, refrigerator panels, gasoline tanks, heat exchanger, furniture components.


Strength of Haomei Al.
  • Technologies:Top polishing technology guarantees good luster and smooth surface.
  • Markets:Obtain market sharing all over the world.
  • Equipment:Advanced cutting line to provide a wide range of specifications.
  • Production capacity:200, 000 tons annually in total.
  • Employees:Over 25 sale persons to provide good service for customers.
  • Responsibility: Engaged in charity donation and provide eco-friendly products.
Packaging and Delivery of Haomei Al.

Aluminum products of Haomei Al. meet the export standard. Plastic film and brown paper can be covered at customers’ need. What’s more, wooden case or wooden pallet is adopted to protect products from damage during the delivery. There are two kinds of packaging, which is eye to wall or eye to sky. Customers can choose either of them for their convenience. Generally speaking, there are 2 tons in one package, and loading 18-22 tons in 1×20′ container, and 20-24 tons in 1×40′ container.
