5086 Aluminum Sheet

sales@aluminumhm.com Get samples and prices !

Cut to size at customers' need !

Add to Product Favorites
Share

Properties of 5086 Aluminum Sheet Plate

5086 aluminum plate has high strength capacity than 5052 and 5083 aluminum plate, but it is not strengthened by heat treatment, instead becoming stronger due to strain hardening or cold mechanical working of the material.3.0%-4.5% of magnesium is added to 5086 aluminum plate, which enable it to have high strength. Heat treatment does not strongly affect the strength, so 5086 aluminum plate can be readily welded and retain most of its mechanical strength. 5086 aluminum plate mainly has four tempers that are vastly used, including 5086-H, 5086-H32, 5086-H112 as well as 5086-H116.

Elements

Si

Fe

Cu

Mn

Mg

Cr

Zn

Ti

Others

Al



Content

0.4

0.5

0.1

0.2-0.7

3.5-4.5

0.05-0.25

0.25

0.15

0.15

Remain



Alloy
 Temper

Specified

Tensile
strength

Yield
strength

Elongation



(mm)

(MPa)

(MPa)

(%)



5086-O

(annealed)

Thickness 0.15-600





Width  30-2600





Length 500-16000

303

97

16



5086-H32

324

193

12



5086-H112

241

96

14



5086-H116

275

193

10



Features and Applications of 5086 Aluminum Sheet

5086 aluminum plate is primarily alloyed with magnesium. Forming characteristics are best with the alloy in the O temper. Machinability in the strain hardened tempers is relatively good. In the annealed (O temper) machining is difficult, but still can be accomplished. For its chemical contents, 5086 aluminum plate has good weld-ability and resistance to salt water correction, which making itself popular for vessel gangways and building boat. However, 5086 aluminum plate has a tendency to undergo stress correction cracking and is not used much in aircraft construction as a result.


Strength of Haomei Al.
  • Technologies:Top polishing technology guarantees good luster and smooth surface.
  • Markets:Obtain market sharing all over the world.
  • Equipment:Advanced cutting line to provide a wide range of specifications.
  • Production capacity:200, 000 tons annually in total.
  • Employees:Over 25 sale persons to provide good service for customers.
  • Responsibility: Engaged in charity donation and provide eco-friendly products.
Packaging and Delivery of Haomei Al.

Aluminum products of Haomei Al. meet the export standard. Plastic film and brown paper can be covered at customers’ need. What’s more, wooden case or wooden pallet is adopted to protect products from damage during the delivery. There are two kinds of packaging, which is eye to wall or eye to sky. Customers can choose either of them for their convenience. Generally speaking, there are 2 tons in one package, and loading 18-22 tons in 1×20′ container, and 20-24 tons in 1×40′ container.
